YTK-QZDG6 Automatic Tomato Paste Shampoo Honey Cosmetics Sauce Gel Peanut Butter Food Filling Machine 1000ml
Automatic paste sachet lip gloss syring donut shampoo viscous jam liquid pouch meat cream filling machine,Desktop honey sauce ice cream filling machine cosmetics lotion cone can filling bottle machine liquid,Automatic bottle jar cream gel peanut butter food soda tomato paste filling machine cosmetic 1000ml
Product description:
The fully automatic piston type liquid filling machine is improved and designed on the basis of the filling machine series, and some additional functions are added. It makes the product more simple and convenient in operation, accuracy error, installation adjustment, equipment cleaning, maintenance and so on. Different high viscosity fluids can be filled. The design of the machine is compact and reasonable, the appearance is simple and beautiful, and the filling volume adjustment is convenient.
The fully automatic type is the empty bottle delivered by the bottle conveying line. Through the bottle feeding dial mechanism, no empty bottle is accurately sent to the turntable, and the empty bottle rotates immediately. After the mouth is in contact with the filling valve, it is automatically opened for filling. After filling, the bottle is automatically pulled out into the bottle conveying line, and the whole process is over. The machine is equipped with an automatic protection device. If the bottle is stuck, the machine will automatically stop to protect the safety of the human and machine.
Product Parameter:
Model |
QZDG2 |
QZDG4 |
QZDG6 |
QZDG8 |
Voltage |
110/220V 50-60HZ 800W |
|||
Filling Range |
5-100ml/10-300ml/50-500ml/100-1000ml/500-3000ml/1000-5000ml |
|||
Working Speed (base on water) |
10-40bottles/min |
20-50bottles/min |
30-70bottles/min |
40-80bottles/min |
Filling Accuracy |
≤+1% |
|||
Conveyor Size |
About 1990*100mm(L*W) |
|||
Size of filling nozzle |
φ10mm |
|||
Size of air compressor connector |
φ10mm |
|||
Machine size |
About 1990*950*1970mm(4 Heads) |
|||
Package weight |
220kg |
260kg |
300kg |
600kg |
Package size |
2000*1200*2300mm |
2000*1200*2300mm |
2500*1300*2300mm |
2800*1300*2500mm |
Product Details:
